| 用途 | 材料 |
|---|---|
| 類型 | 標準料 |
| 牌號 | OLLOY 歐龍優 |
| 用途級別 | 電動工具配件,電線電纜級,電子電器部件,管材級,家電部件,汽車部件,通用級 |
| 廠家(產地) | 自產 |
| 加工級別 | 注塑級,擠出級 |
| 特性級別 | 高光澤,高滑動,高抗沖,高流動,熱穩定性,標準級,高剛性,耐磨,耐高溫,耐低溫,高強度,增強級,阻燃級,增韌級,抗靜電,耐老化 |
無鹵阻燃MPPO(MPPE)電纜外被料
OLLOY KMDE為電線電纜擠出系列產品原料,，具有優異的柔韌性,、阻燃性能和表面光潔度,，被廣泛地應用于直流電電線,，電氣產品電線,，電子線,，信號線,，以及電信設施電線,，汽車配線等等,。目前本公司的該系列產品已經成為國內外知名電子和通訊設備品牌重點使用的無鹵線材原材料。
OLLOY KMDE series of products have excellent flexibility, flame resistance and surface finish. These materials are widely used for various of DC cables,electrical product wires , earphone cables, USB cables, computer peripheral cables, electronic wires, signal lines, telecommunication facilities cables and Various automotive wires,etc. At present, our company’s products have become key non-halogen wire materials of well-known brands of electronic and communications equipment.
1,、OLLOY KMDE系列產品性能（The physical date）
Unit | Standard | KMDE95L KMDE90L KMDE85L KMDE80L KMDE75L KMDE65L | |
Hardness, Shore A |
| ASTM ISO868 | 95 90 85 80 75 65 |
Specific Gravity |
| D790 | 1.05 1.04 1.06 1.08 1.08 1.08 |
Tensile Stress, brk | MPa | D638 | 23.3 19.5 16.6 15.5 13.0 10.2 |
Tensile Elongation, brk | % | D638 | 260 230 232 215 205 192 |
Tensile Stress retention rate, brk after 7days @113°C | MPa | UL1581 | 106 105 108 103 108 91 |
Tensile Elongation Retention Rate,brk after 7days @113°C | % | UL1581 | 94 95 88 89 83 81 |
Thermal Shocks(1hr@121°C) |
| UL1581 | No cracks No cracks No cracks No cracks No cracks No cracks |
Brittleness Temperature | ℃ | D746 | <-40 <-40 <-40 <-40 <-40 <-40 |
UL Temperature Rating | ℃ | UL1581 | 80 80 80 80 80 80 |
Volume Resistivity | Ohm-cm | D257 | 4.0E+15 4.3E+15 4.0E+15 3.8E+15 3.8E+15 1.8E+15 |
Relative Permittivity, 60 Hz |
| D150 | 2.5 3.2 3.5 2.6 3.0 3.5 |
Flammability |
| UL1581 | VW-1 V W-1 V W-1 VW-1 VW-1 VW-1 |
Smoke Density, Non-flame, Ds, max Flame, Ds, max | Dm Dm |
E662 E662 |
80 85 82 81 86 85 140 142 143 138 146 147 |
注：以上數據僅供參考,，不能作為我公司質量保證依據。用戶可根據您公司設備實際情況及電纜結構具體形式對我公司產品進行應用和適應,。
2,、OLLOY KMDE系列產品 Parameter ofwire coating extrusion:
1、Please drying material before extruding processing:
Drying Temperature :80-90°C; drying time:2-3hrs
2,、Extruding temperature(°C):
Feed Zone Temperature: 180-190 Middle Zone Temperatures : 200-210 Head Zone Temperature:200-210
Neck Temperature: 200-210 Cross-head Temperature: 210-220 Die Temperature:200-220
Melt Temperature:200-220
