| 內徑 | 220（mm） |
|---|---|
| 外徑 | 276（mm） |
| 厚度 | 26（mm） |
| 重量 | 111（kg） |
| 保持架及其材料 | 鋼板 |
| 使用特性 | 耐腐蝕 |
| 用途 | 挖掘機 |
| 滾動體列數 | 單列 |
| 滾道類型 | 深溝滾道 |
| 樣品或現貨 | 現貨 |
| 類型 | 其他 |
| 工作原理 | 滾動 |
| 軸承材質 | 高碳鉻軸承鋼（全淬透型)(GCr15) |
| 品牌 | NSK |
| 型號 | BA220-6ASA |
| 經營挖掘機專用軸承 | |||||
| 型號 | 尺寸 | 型號 | 尺寸 | ||
| BA180-4WSA | 250*180*33 | AC4631 | 310*230*40 | ||
| BA220-6ASA | 276*220*26 | AC5836 | 355*289*34 | ||
| BA222-1 | 222*276*26 | AC5033 | 250*330*37 | ||
| BA230-7 | 230*300*35 | AC523438-1 | 340*260*38 | ||
| BA240-3WSA | 240*310*33.5 | AC6037-1 | 370*300*33 | ||
| BA205-1 | 295*205*40 | AC463240 | 320*230*40 | ||
| BA250-4A | 330*250*38 | LM639249/10 | 196.85*241.323.812 | ||
| BA260-4A | 260*340*38 | LM540049/10 | |||
| BA280-2A | 370*280*40 | LM739749/10 | 196.85*257.175*39.688 | ||
| BA260-3A | 340*260*36 | R196Z-4 | 196.85*241.3*12 | ||
| BA289-1 | 355*289*33 | T2ED045-1 | |||
| BA290-3A | 380*290*40 | 4T-T7FC065 | 178*216*20 | ||
| 180BA-2256 | 180*225*22 | T7FC055 | |||
| 184BA-2251 | 184*226*19 | LL429349/10 | |||
| SF3227PX1 | 200*160*10 | LL225749/10 | |||
| SF3235PX1 | 330*260*35 | LL327049/10 | |||
| SF4444PX1 | 295*220*32 | 561904P6X | |||
| SF4454PX1 | 220*295*33 | 64450/64700 | |||
| SF4815PX1 | 310*240*33 | 74500/74850 | |||
| SF4615PX1 | 230*300*33 | JP14049/10 | |||
| SF4826PX1 | BA246-2A | 313*246*32 | |||
| SF4852PX1 | 240*310*33 | BD130-1 | 130*166*34 | ||
| SF4831PX1 | 310*240*25 | SF5811pX1 | 290/380/40 | ||
| SF4007PX1 | 250*200*24 | BA245-2A | |||
| SF3607PX1 | 225*180*21 | SF4860 | 240*320*38 | ||
| SF5235PX1 | 260*355*40 | BA270 | 270*350*40 | ||
| 供應車形：挖掘機軸承.挖掘機行走軸承.挖掘機回轉軸承， | |||||
| 挖掘機液壓泵軸承.神鋼挖掘機軸承.小松挖掘機軸承. | |||||
| 卡特挖掘機軸承.加藤挖掘機軸承.日立挖掘機軸承. | |||||
| 大宇挖掘機軸承.現代挖掘機軸承.沃爾沃挖掘機軸承.... | |||||
包裝:單個紙盒包裝或普通工業包裝
交貨及時，恪守信譽
互惠互利，雙方共贏
動靜自如 運轉無憂
臨西縣華富軸承有限公司按照ISO國際標準和GB國家標準專業生產深溝球軸承,公制圓錐滾子軸承,英制圓錐滾子軸承，車橋軸承,拖車軸承,后輪轂軸承。公司在2005年新上汽車后輪轂用圓錐滾子軸承生產線,致力于后輪轂圓錐滾子軸承的開發,產品暢銷澳洲，歐美，中東，東南亞市場。
LM11749/10 | 17.462 | 39.878 | 13.843 | 14.605 | 10.668 | 1.3 | 1.3 |
| LM11949/10 | 19.05 | 45.237 | 15.494 | 16.637 | 12.065 | 1.3 | 1.3 |
| M12649/10 | 21.43 | 50.005 | 17.526 | 18.288 | 13.97 | 1.3 | 1.3 |
| LM12749/10 | 21.986 | 45.237 | 15.494 | 16.637 | 12.065 | 1.3 | 1.3 |
| LM12749/11 | 21.986 | 45.974 | 15.494 | 16.637 | 12.065 | 1.3 | 1.3 |
| L44643/10 | 25.4 | 50.292 | 14.224 | 14.732 | 10.668 | 1.3 | 1.3 |
| M84548/10 | 25.4 | 57.15 | 19.431 | 19.431 | 14.732 | 1.5 | 1.5 |
| L44649/10 | 26.988 | 50.292 | 14.224 | 14.732 | 10.668 | 3.5 | 1.3 |
| L45449/10 | 29 | 50.292 | 14.224 | 14.732 | 10.668 | 3.5 | 1.3 |
| LM67048/10 | 31.75 | 59.131 | 15.875 | 16.764 | 11.811 | 1.3 | |
| LM67049A/10 | 31.75 | 59.131 | 15.875 | 16.7 | 12 | 4 | 1.7 |
| 15123/245 | 31.75 | 62 | 18.161 | 19.05 | 14.288 | 1.3 | |
| 2580/20 | 31.75 | 66.421 | 25.4 | 25.357 | 20.638 | 0.8 | 3.3 |
| M88048/10 | 33.338 | 68.262 | 22.225 | 22.225 | 17.462 | 0.8 | 1.5 |
| LM48548/10 | 34.925 | 65.088 | 18.034 | 18.288 | 13.97 | 1.3 | |
| 25877/20 | 34.925 | 73.025 | 23.812 | 24.608 | 19.05 | 1.5 | 2.3 |
| 25877/21 | 34.925 | 73.025 | 23.812 | 24.608 | 19.05 | 1.5 | 0.8 |
| 2793/20 | 34.925 | 76.2 | 23.812 | 25.654 | 19.05 | 0.8 | 3.3 |
| 31594/20 | 34.925 | 76.2 | 29.37 | 28.575 | 23.812 | 1.5 | 3.3 |
| 3872/20 | 34.925 | 85.725 | 30.162 | 30.162 | 23.812 | 3.5 | 3.3 |
| L68149/10 | 35 | 59.131 | 15.875 | 16.764 | 11.938 | 1.3 | |
| L68149/11 | 34.988 | 59.974 | 15.875 | 16.764 | 11.938 | 1.3 | |
| JL69349/10 | 38 | 63 | 17 | 17 | 13.5 | 1.3 | |
| 2776/20 | 38.1 | 76.2 | 23.812 | 25.654 | 19.05 | 4.3 | 3.3 |
| 2788/20 | 38.1 | 76.2 | 23.812 | 25.654 | 19.05 | 3.5 | 3.3 |
| 418/414 | 38.1 | 88.5 | 26.988 | 29.083 | 22.225 | 3.5 | 1.5 |
| 2789/20 | 39.688 | 76.2 | 23.812 | 25.654 | 19.05 | 3.5 | 3.3 |
| HM801349/10 | 40.483 | 82.55 | 29.37 | 28.575 | 23.02 | 3.5 | 3.3 |
| LM300849/11 | 40.988 | 67.975 | 17.5 | 18 | 13.5 | 1.5 | |
| 18590/20 | 41.275 | 73.025 | 16.667 | 17.462 | 12.7 | 3.5 | 1.5 |
| LM501349/10 | 41.275 | 73.431 | 19.558 | 19.812 | 14.732 | 3.5 | 0.8 |
| LM501349/14 | 41.275 | 73.431 | 21.43 | 19.812 | 16.604 | 3.5 | 0.8 |
| 11162/300 | 41.275 | 76.2 | 18.009 | 17.384 | 14.288 | 1.5 | 1.5 |
| 25578/20 | 42.862 | 82.931 | 23.812 | 25.4 | 19.05 | 2.3 | 0.8 |
| 25580/20 | 44.45 | 82.931 | 23.812 | 25.4 | 19.05 | 3.5 | 0.8 |
| 25582/20 | 44.45 | 82.931 | 24.812 | 26.4 | 20.05 | 5 | 0.8 |
| HM803149/10 | 44.45 | 88.9 | 30.162 | 29.37 | 23.02 | 3.5 | 3.3 |
| 3782/20 | 44.45 | 93.264 | 30.162 | 30.302 | 23.812 | 3.5 | 3.3 |
| 3776/20 | 44.983 | 93.264 | 30.162 | 30.302 | 23.812 | 3.5 | 3.3 |
| LM102949/10 | 45.242 | 73.431 | 19.558 | 19.812 | 15.748 | 3.5 | 0.8 |
| LM603049/11 | 45.242 | 77.788 | 19.842 | 19.842 | 15.08 | 3.5 | 0.8 |
| 25590/20 | 45.618 | 82.931 | 23.812 | 25.4 | 19.05 | 3.5 | 0.8 |
| 25590/22 | 45.618 | 83.058 | 23.876 | 25.4 | 19.114 | 3.5 | 2 |
| 25590/23 | 45.618 | 82.931 | 26.988 | 25.4 | 22.225 | 3.5 | 2.3 |
| LM503349A/10 | 45.987 | 74.976 | 18 | 18 | 14 | 1.5 | |
| 18690/20 | 46.038 | 79.375 | 17.462 | 17.462 | 13.495 | 2.8 | 1.5 |
| 359A/354A | 46.038 | 85 | 20.638 | 21.692 | 17.462 | 3.5 | 1.3 |
| 3778/20 | 47.625 | 93.264 | 30.162 | 30.302 | 23.812 | 6.4 | 3.3 |
| JLM104948/10 | 50 | 82 | 21.5 | 21.5 | 17 | 3 | 0.5 |
| LM104949/11 | 50.8 | 82.55 | 21.59 | 22.225 | 16.51 | 3.5 | 1.3 |
| 18790/20 | 50.8 | 85 | 17.462 | 17.462 | 13.495 | 3.5 | 1.5 |
| 18790/24 | 50.8 | 88.9 | 18.462 | 18.462 | 14.495 | 3.5 | 1.3 |
| 3780/20 | 50.8 | 93.264 | 30.162 | 30.302 | 23.812 | 3.5 | 3.3 |
| 387/382A | 57.15 | 96.838 | 21 | 21.946 | 15.875 | 2.3 | 0.8 |
| 387A/382A | 57.15 | 96.838 | 21 | 21.946 | 15.875 | 3.5 | 0.8 |
| 387AS/382A | 57.15 | 96.838 | 21 | 21.946 | 15.875 | 5 | 0.8 |
| 387S/382A | 57.15 | 96.838 | 21 | 21.946 | 15.875 | 0.8 | 0.8 |
| 462/453X | 57.15 | 104.775 | 30.162 | 29.317 | 24.605 | 2.3 | 3.3 |
| 29580/20 | 60 | 107.95 | 25.4 | 25.4 | 19.05 | 3.5 | 3.3 |
臨西縣華富軸承有限公司按照ISO國際標準和GB國家標準專業生產深溝球軸承,公制圓錐滾子軸承,英制圓錐滾子軸承，車橋軸承,拖車軸承,后輪轂軸承。公司在2005年新上汽車后輪轂用圓錐滾子軸承生產線,致力于后輪轂圓錐滾子軸承的開發,產品暢銷澳洲，歐美，中東，東南亞市場。
